• H.265+/H.265/H.264+/H.264 video formats
• Up to 16-ch IP camera inputs
• Up to 16-ch@4MP decoding capacity
• Up to 256 Mbps incoming bandwidth
• Up to 8-ch IP speakers can be connected

Specification

• Video and Audio

• IP Video Input

  16-ch

  Up to 32 MP resolution

  *: After ultra HD resolution mode is enabled, the NVR supports up to 8-ch 32 MP/24 MP IP video inputs.

• Incoming Bandwidth 256 Mbps
• Outgoing Bandwidth 256 Mbps
• HDMI Output 8K (7680 × 4320)/30Hz, 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz
• VGA Output 1920 × 1080/60Hz
• Video Output ModeHDMI/VGA independent output
• CVBS Output 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
• Audio Output 1-ch, RCA (Linear, 1 KΩ)
• Two-Way Audio 1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)

• Decoding

• Decoding Format H.265+/H.265/H.264+/H.264
• Recording Resolution

  32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/ 2CIF/CIF/QCIF

  *: After ultra HD resolution mode is enabled, the NVR supports up to 8-ch 32 MP/24 MP IP video inputs.

• Synchronous Playback 16-ch
• Decoding Capability 2-ch@32 MP (30 fps)+2-ch@8MP（30fps）/10-ch@8 MP (30 fps)/20-ch@4 MP (30 fps)/40-ch@1080p (30 fps)
• Dual-Stream Recording Support
• Stream Type Video, Video & Audio
• Audio Compression G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2

• Network

• Remote Connection 128
• Network Protocol TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS, ONVIF(Version 2.2), OTAP
• Network Interface 1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
• Camera Access Protocol ONVIF(Version 2.5), RTSP

• PoE

• Interface 16, RJ-45 10/100 Mbps self-adaptive Ethernet interface
• Power ≤ 200 W
• Standard IEEE 802.3 af/at

• Auxiliary Interface

• SATA 2 SATA interfaces
• Capacity Up to 16 TB capacity for each disk
• Alarm In/Out 4/1
• USB Interface Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0

• General

• Power Supply 100 to 240 VAC, 50 to 60 Hz
• Consumption ≤ 15 W (without HDD and PoE off)
• Working Temperature -10 °C to 55 °C (14 °F to 131 °F)
• Working Humidity 10% to 90%
• Dimension (W × D × H) 385 × 315× 52 mm (15.2" × 12.4" × 2.0");≤ 3 kg (without HDD, 2.2 lb.)

• Certification

• FCC Part 15 Subpart B, ANSI C63.4-2014
• CE

  EN 55032:2015+A1:2020, ENIEC61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:201

  9, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020
